The Fusion Valvevolution HDPE male threaded valve series with adaptor, made of single-body HDPE, ensures high levels of safety and resistance to operating temperatures and pressures. It is ideal for connecting polyethylene pipes (PELD, PEMD and PEHD) in the distribution of pressurised fluids and is tested to guarantee a PN16 working pressure. The brass ball and pin are completely enclosed in their casing, which guarantees no stagnation or encrustation that would compromise the quality of the drinking water.
The Fusion male threaded ball valve in HDPE is connected to the circuit via the two tangs and by butt welding or electrical sleeve and via BSP male thread (or NPT on request). It stands out for its ease of installation in all civil and industrial water distribution and heating systems, in geothermal systems, and in aqueducts.
GENERAL CATALOGS AND TECHNICAL DATA SHEETS IN
VARIANT SIZE BOX
18VCME-B-2-P ½” x 20 60
18VCME-C-3-P ¾” x 25 35
18VCME-D-4-P 1” x 32 25
18VCME-E-6-P 1” ¼ x 40 18
18VCME-F-7-P 1” ½ x 50 8
18VCME-G-8-P 2” x 63 6
MIN= -15°C MAX= +80°C
REGULATION FOR DRINKING WATER:
DM 174-06/04/2004 (Italy), DM 23/04/2009 e Reg. UE n° 10/2011
- Prove [Tests]: ISO 9393-1 : 2004 – ISO 9393-2 : 2005
